Drawing, device to move water using air by unknown author
Reference number: CLP/3i/61
Date: 17th century
Description
Drawing and explanation showing a device used to move water with the use of air. Includes a description of how the water travels through the device. The drawing shows a vessel from which water is withdrawn. A pipe runs from the vessel up and then down through three boxes.
The drawing and description are clearly in the same hand as the drawing found at CLP/3i/62.
Subject: Engineering / Physics
- Reference number
- CLP/3i/61
- Earliest possible date
- 17th century
- Physical description
- Ink on paper
- Page extent
- 1 page
- Format
- Drawing
