Unpublished paper, 'Description of a quadrant for measuring horizontal angles by reflection' by W [William] Barnes
Reference number: AP/14/3
Date: 1830

Description
Barnes describes the construction of his quadrant used to measure horizontal angles. The quadrant consists of a frame, an arch, a nonius, an index glass, an object glass, and a light vane. Includes a separate page of illustrations. The covering letter for this paper is found at AP/14/1/1.
Subject: Scientific Instruments
Received by the Royal Society on 7 August 1830.
- Reference number
- AP/14/3
- Earliest possible date
- 1830
- Physical description
- Ink on paper
- Page extent
- 7 pages
- Format
- Manuscript
